Z3F
- 产品认证：
-
● CQC证书号: CQC21002296112
● TUV证书号: R50503935
● UL证书号: E502082
- PDF下载：
-
- 典型应用：
-
● 家用电器：空调、电热器等 Home appliances: air conditioner, electric heater, etc.
● OA设备：电脑、传真机等 OA Equipment: computer, fax machine, etc.
● 自动售货机 Vending Machine
● 10A/16A 250VAC 切换容量 Switching capability ● 密封型和非密封型选择 Plastic sealed and flux proofed types available ● 一组常开、一组转换触点形式 1Form A and 1Form C configurations ● 线圈功耗低 Low coil power consumption ● 环保产品（符合ROHS）Environmentally-friendly product (compliant with RoHS) |
Z3F | -12 | -1 | A | S | ||||
基本型号 Type Z3F | ||||||||
线圈额定电压 Coil Voltage 03，05，06，09，12，24 | ||||||||
接点极数 Contact Pole 1-1极Pole | ||||||||
触点结构 Contact of Arrangement 1A=1FormA常开型; 1B=1FormB常闭型; 1C=1FormC转换型 | ||||||||
封装形式Enclosure 空白Blank=非密封型Vented Plastic Case; S=密封型Sealed Plastic Case; | ||||||||
触点负载Contact Load 无Blank=标准型Standard 10A; F=高负载型High Load 16A | ||||||||
线圈功耗 Coil Power 无Blank=0.36W H=0.5W | ||||||||
特殊标记 Suffix Blank=Standard, (XXX)=客户特殊需求 Customer Special Requirement | ||||||||
