Z2F
- 产品认证：
-
●CQC证书号 CQC Certificate number: CQC21002296113
●TUV证书号 TUV Certificate number: R50503055
●UL证书号 UL Certificate number: E502802
- PDF下载：
-
- 典型应用：
-
● 家用电器：空调、电热器等 Home appliances: air conditioner, electric heater, etc.
● OA设备：电脑、传真机等 OA Equipment: computer, fax machine, etc.
● 自动售货机 Vending Machine
●10A触点切换能力，有16A可选 10A contact switching capability, 16A optional ●塑封型和防焊剂型 Plastic seal type and flux proof type ●线圈触点间耐压4KV Designed to meet 4kv dielectric between coil and contacts ●可提供敏感型和标准型线圈 Sensitive and standard coils available ●环保产品（符合ROHS）Eco-friendly products (ROHS compliant) ●外形尺寸 Overall dimension: 18.2X10.2X14.6mm |
Z2F | -12 | D | H | -1 | A | S | X | |
基本型号 Type Z2F | ||||||||
线圈额定电压 Coil voltage 05=5VDC, 06=6VDC, 09=9VDC, 12=12VDC, 24=24VDC | ||||||||
线圈功耗 Coil Power D=0.36W L=0.2W | ||||||||
触点负载Contact Load 空白 Blank=5A; H=10A; T=16A | ||||||||
接点极数 Contact Pole 1-1极Pole | ||||||||
触点结构 Contact of arrangement 1A=1FormA常开型 | ||||||||
封装形式Enclosure 空白Blank=非密封型Vented Plastic Case; S=密封型Sealed Plastic Case | ||||||||
特殊标记 Suffix Blank=Standard, (XXX)=客户特殊需求 Customer Special Requirement | ||||||||
