Z10F
- 产品认证：
- PDF下载：
-
- 典型应用：
-
● 光伏新能源：充电桩、OBC、电源模块、光伏逆变等
EV charging station, OBC, APM, Photovoltaic, etc.
● 35A 277VAC以上切换容量，有40A/50A 277VAC可选 35A 277VAC switching capacity or higher, with options of 40A/50A 277VAC ● 触点与线圈间介质耐压5KV Dielectric strength between the contacts and the coil: 5KV ● 触点间隙1.8mm可选，符合欧洲VDE0126光伏标准 Contact gap options of 1.8mmmm, compliant with European photovoltaic standard VDE0126 ● 低功耗，低温升，低保持；40A/50A载流温升低与50K Low power consumption, low temperature rise, low holding power; low current temperature rise of 40A/50Aand 50K ● 具有一组常开 Equipped with a set of normally open contacts ● 线圈功耗 0.9W/1.4W/1.6W/3.8W Coil power consumption: 0.9W/1.4W/1.6W/3.8W |
Z10F | ||||||||
基本型号 Type Z10: PCB端子 | ||||||||
线圈额定电压 Coil Voltage 05，09，12，24，48 | ||||||||
线圈功耗 Nominal Power Blank=0.9W,L=1.4W,D=1.6W,H=3.8W | ||||||||
触点结构 Contact of Arrangement 1A=Form1A | ||||||||
封装形式 Category of Protection Blank=非密封型 Flux proof, S=密封型 Wash Tight | ||||||||
负载类型 Rating Blank=35A 250VAC, T40=40A 250VAC, T50=50A 250VAC, | ||||||||
触点间隙 Contact Gap Blank=标准间隙Standard, G=大间隙Big Gap (1.8mm) | ||||||||
特殊标记 Suffix Blank=Standard, (XXX)=客户特殊需求 Customer Special Requirement | ||||||||
