Z15K
- 产品认证：
- PDF下载：
-
- 典型应用：
-
● 家用电器：空调、电热器等 Home Appliances: air conditioner, electric heater, etc.
● 智能家居：Housing Equipment: building automation, smart home application, etc.
● 20A触点切换容量 20A
switching capability
● 触点与线圈间介质耐压5KV
5KV dielectric strength (between coil and contacts)
● 具有单线圈与双线圈可供选择
Both 1 coil and 2 coils available
● 低高度仅15.7mm
Low height: 15.7mm
Z15K | -12 | A | XXX | |||
基本型号 Type Z15K | ||||||
线圈额定电压 Coil voltage 03，05，06，09，12，18，24VDC | ||||||
线圈 Coil Sort Blank=1 coil; 2=2 coils | ||||||
触点结构 Contact of Arrangement 1A=1Form A; 1C=1Form C；2A=2Form A; 2C=2Form C | ||||||
封装形式 Category of Protection Blank=非密封型 Flux proof; S=密封型 Wash tight | ||||||
特殊标记 Suffix Blank=Standard, (XXX)=客户特殊需求 Customer Special Requirement | ||||||
